GBH 2-28 DFV Professional Rotary Hammer with SDS plus

The most powerful tool in its class

• Highest drilling rate and highest chiselling performance in its class
• 25% longer lifetime than other rotary hammers in its class for more efficiency
• 27% less vibration than the predecessor model due to active vibration damping

• Performance data

  Impact rate at rated speed

  0 – 5,100 bpm

  Rated speed

  0 – 1,300 rpm

  Additional data

  Rated input power

  850 W

  Impact energy

  3.2 J

  Tool holder

  SDS plus

  Weight

  3.1 kg

  Drilling range

  Drilling dia. concrete, hammer drill bits

  4 – 28 mm

  Opt. appl. range concrete, hammer drill bits

  8 – 16 mm

  Drilling diameter in concrete with core cutters

  16 – 68 mm

  Drilling dia. concrete, dust extraction unit

  4 – 16 mm

  Total vibration values (Hammer drilling in concrete)

  Vibration emission value ah

  11 m/s²

  Uncertainty K

  1.5 m/s²

  Total vibration values (Chiselling in concrete)

  Vibration emission value ah

  11 m/s²

  Uncertainty K

  1.5 m/s²

  Hammer drilling in concrete

  Vibration emission value ah

  11 m/s²

  Uncertainty K

  1.5 m/s²

  Chiselling in concrete

  Vibration emission value ah

  11 m/s²

  Uncertainty K

  1.5 m/s²
