GTC600 C Professional Thermo Camera

Detailed visualisation of temperature differences with smart documentation

• High thermal resolution and wide measuring range for maximum applications
• Voice note and Bosch ThermalOn app enable easy documentation of thermal images
• Intuitive user interface and seamlessly integrated features deliver successful results in minimum clicks

• Additional data

  Battery voltage

  12.0 V

  Measurement range

  -20 °C to +600 °C

  Measuring accuracy of IR

  ± 2.0 °Cᵇ

  Measuring application

  Thermal image

  Data transfer

  Wi-Fi, USB-C®

  Thermal sensitivity (NETD)

  <=50 mK

  Size of IR sensor

  256 Pixel x 192 Pixel

  Resolution

  0.1 °C

  Number of measuring points

  49,152

  Power supply and runtime

  GBA 12 V 2.0 Ah 6 hours

  Frame buffer (number of images)

  600

  File format of image

  .jpg

  Shock protection

  2 m

  Dust and splash protection

  IP54** (**except for the lithium-ion battery pack)

  Weight

  0.6 kg

  Size of display

  3,5″

  Operating temperature

  -10 – 45 °C

  Storage temperature

  -20 – 50 °C

  Focus distance, minimum

  0.3 m

  Thermal image refresh rate

  9 Hz

  Frame buffer (number of images each with audio)

  350

  File format of audio

  .wav
