Features
- Variable 2-speed design (0-450 & 0-1,700 RPM) covers a wide range of drilling and driving applications.
- 12V max slide battery design enables the tool to stand on its own for user convenience.
- Multi-contact terminals ensure stable contact with battery even under extreme vibration.
- Battery protection circuit protects against overloading, over-discharging and over-heating.
- Convenient 6.35 mm (1/4″) Hex chuck for quick bit changes.
- 20 clutch settings and drill mode for added fastening control.
- Mechanical 2-speed gearing; High speed mode for speedy drilling in light duty applications; Low speed mode for heavy duty applications requiring high torque.
- Electric brake for maximum productivity and increased operator safety.
Specification

Capacity | Steel: 10 mm (3/8″) Wood: 21 mm (13/16″) |
Chuck Capacity | 6.35 mm (1/4″) |
Max Fastening Torque | Hard: 30 N·m (270 in. lbs) | Soft: 14 N·m (130 in. lbs.) |
Max Lock Torque | 28 N·m (250 in. lbs.) |
No Load Speed (RPM) | High: 0 – 1700 | Low: 0 – 450 |
Dimensions (L x W x H) | 149 x 66 x 212 mm (5-7/8 x 2-5/8 x 8-3/8″) |
Net Weight | 0.9 – 1.1 kg (2.1 – 2.4 lbs.) |
Work Amount (approx.) | 160 holes with BL1021B Wood Drilling Ø 3 x 1.6 mm |
Standard Equipment Phillips Bit, Belt Clip Available Option |
