TOKU MV6226B: Air Clutch Type Screw Driver, Hex Drive 1/4″
WhatsApp us
Description
Model: MV6226B
Toku MV6226B is an air clutch type screw driver.
- Made in Japan
Features
- Compact light weight
- Adjustable torque.
- Ideal for light assembly industries.
Specifications
| Hexagon Drive (inches) | 1/4 |
| Bolt Size (mm) | 6 |
| Torque Range (kg.m) | 0.5-1.2 |
| Maximum Torque (kg.m) | 1.2 |
| Net Weight (kg) | 1.3 |
| Overall Length (mm) | 205 |
| Free Speed (rpm) | 1800 |
| Avg. Air Consumption | 0.60 m3/min |
| Air Inlet (pt) | 1/4 |
| Hose Size (inches) | 1/4 |
| Shank Size | N/A |
- Air pressure required : 6 kg/cm2 = 6 bar
- Torque : 1.0 kg.m = 9.807Nm = 7.233 ft.lb
- All impact wrench contains forward and reverse actions
