Neovin Multistage Booster Pump

APPLICATION

-Works ideally with clean and non-volatile liquids (without fibers or solid partilcle)

-Suitable to boost water supply in hilly areas , for agricultural , commercial and residential

uses . It is ideal for pumping water up through a high-rise building while maintaining constant pressure

 MATERIAL

-lmpeller: Stainless steel

-Diffusers: Stainless steel

-Motor shaft: Stainless steel

-Mechanical seal: Carbon/Silicon

-Pump body: Cast iron for CH-M series; Stainless steel for SH-M sEries

-Pump casing: Cast iron for CH-M series; Stainless steel for SHiil series

APPLICATION LIMIT :

-Liquid temperature up to 7O’C

-Max working pressure 10bar

-Flow rates up to 110LPM

– Head up to 58m

Specification

*CH-M230/SH-M230*

1. Maximum Flow Rate, Q = 3.5m³/h
2. Maximum Head = 28m
3. Rated Power = 0.37kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1 x 1 inch

*CH-M240/SH-M240*

1. Maximum Flow Rate, Q = 3.5m³/h
2. Maximum Head = 38m
3. Rated Power = 0.55kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1 x 1 inch

*CH-M250/SH-M250*

1. Maximum Flow Rate, Q = 3.5m³/h
2. Maximum Head = 48m
3. Rated Power = 0.55kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1 x 1 inch

*CH-M440/SH-M440*

1. Maximum Flow Rate, Q = 7m³/h
2. Maximum Head = 38m
3. Rated Power = 0.75kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1¼ x 1 inch

*CH-M450/SH-M450*

1. Maximum Flow Rate, Q = 7m³/h
2. Maximum Head = 48m
3. Rated Power = 1.00kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1¼ x 1 inch

*CH-M460/SH-M460*

1. Maximum Flow Rate, Q = 7m³/h
2. Maximum Head = 58m
3. Rated Power = 1.10kW
4. Rated Voltage = 240V / 50Hz
5. Inlet x Outlet = 1 x 1 inch
