EZYLIF BENCH DRILLING MACHINE VD13

SPECIFICATION
Model: VD13
Max Driling Diameter: 13 mm (1/2″)
Motor Power: 375 w
Spindle Travel: 50 mm
Class of Speed: 5
Speed 50Hz: 620-2620 rpm
Spindle Taper: B16

Max Distance:
• Spindle axis to surface of column – 105 mm
• Spindle end to surface of table – 220 mm
• Spindle end to surface – 300 mm

Swing: 210 mm
Table Size: 160 x 160 mm
Base Size: 290 x 190 mm
Column Diameter: 46 mm
Height: 580 mm
Packing Dimension: 430 x 340 x 230 mm
