DTD173RTJ/ Z 18V Cordless Impact Driver
WhatsApp us
Features
- 18V LXT BL Cordless Wood/Bolt/T-Mode 180 N·m (1,590 in.lbs.) Impact Driver.
- We have reduced the operator’s burden and improved operability by revising the layout of the battery and the switch panel from DTD172 and slimming down the entire circumference of the head.
- Illumination shadows have been significantly reduced by adopting a ring illumination LED.
- Slim tool body
The protrusions on the LED sections on both sides have been eliminated, improving the screwdriving performance in tight corners or confined spaces. - Ring illumination LED
• The LED emits light in a ring shape from the tip of the hammer case, significantly reducing the shadow of the bit.
• The brightness (3 stages) can be changed by pressing and holding the mode switch button.
Specification
| Capacity | Machine Screw: M4 – M8 (5/32 – 5/16″) Standard Bolt: M5 – M16 (3/16 – 5/8″) High Strength Bolt: M5 – M14 (3/16 – 9/16″) Coarse Thread (in length): 22 – 125 mm (7/8″ – 4-7/8″) Wood (Auger Bit): 24 mm (15/16″) |
| Hex Shank | 6.35 mm (1/4″) |
| Impacts Per Minute (IPM) | Max: 0 – 3,800 | Hard: 0 – 3,600 Med.: 0 – 2,600 | Soft: 0 – 1,100 |
| Max Fastening Torque | 180 N·m (1,590 in. lbs.) |
| No Load Speed (RPM) | Max: 0 – 3,600 | Hard: 0 – 3,200 Med.: 0 – 2,100 | Soft: 0 – 1,100 |
| Dimensions (L x W x H) | 111 x 81 x 234 mm (4-3/8 x 3-3/16 x 9-1/4″) |
| Net Weight (with battery) | 1.5 kg (3.3 lbs) |
| Work Amount (approx.) | 970 pcs with BL1860B Coarse thread screw 65 mm at max impact mode |
| Standard Equipment Belt ClipAvailable Options RTJ: 1x Rapid Charger, 2x 5.0Ah Battery, 1x Makpac Connector Box Type 2 Z : Without Charger, Battery & Carrying Case |
|
