Features
- By adopting a horizontal crank type counterweight, vibration is reduced much lower than the competing models, reducing hand fatigue during operation
- High cutting speed (Max 3,000min-ı) with 32mm stroke length provide high cutting efficiency
- Compatible with a wide range of cutting applications; Variable speed control by dial (1,000 – 3,000min-ı) enables user to adjust the max cutting strokes to match the material of workpiece; Extended blade life in stainless cutting applications thanks to max strokes lowered to 1,000min-ı
- Blade ejection lever is relocated to the side of the housing for increased convenience in removing the blade
- Anti-drop mechanism for Shoe; minimizes drop of shoe when adjusting the position of Shoe; Shoe can be removed simply by operating a lever and a button
- Ergonomically designed handle fits your hand well, even during difficult cutting applications such as overhead application, cutting with the saw upside down, etc
- Tool-less shoe adjustment; Lever system is employed instead of button system. It minimizes the blade lock from unintentional releasing
- Tool-less blade change; Redesign of blade clamp makes it easier to remove a blade
- Retractable tool hook allows to hang the machine on ladder rungs or guard rails of aerial work platform
- Constant speed control minimizes reduction in cutting speed under load
Specification

Capacity | Wood: 255 mm (10″) Pipe: 130 mm (5-1/8″) |
Length of Stroke | 32 mm (1-1/4″) |
Strokes Per Minute (SPM) | 0- 3,000 |
Dimensions (L x W x H) | 451 x 97 x 256 mm (17-3/4 x 3-13/16 x 10-1/8″) |
Net Weight | 4.6 – 5.8 kg (10.1 – 12.8 lbs.) |
Work Amount (approx.) | 55 Cuts with BL4025 Carbon steel pipe (25A) |
* Recommended batteries 2.0 Ah, 2.5 Ah, 4.0 Ah, 4.0 Ah (F), 5.0 Ah
Standard Equipment Available Options |
