HPT INVERTER SUBMERGED ARC WELDING MACHINE DCI12
WhatsApp us
MULTI PROCESS WELDER 1300 AMPS
Features:
- Suitable for CC – CV SAW, MIG , FLUX CORED, Gouging
- Can be integrated for semi and full automatic welding
- 100 % duty cycle at 1000 amps @ 44V
- Ready connection to lincoln and miller wire feed controllers
- Adjustable inductance and bumback control
- Proven IGBT inverter design for better efficiency and low power consumption
| Specification | Unit | DCI – 12 |
| Rated Input Voltage & Phase | VAC | 415, 3 |
| Rated Frequency | Hz | 50 / 60 |
| Rated Voltage Fluctuation | % | ± 15 |
| Rated Input | KW
KVA |
32.8
40.9 |
| Welding Mode | — | CC / VV |
| Constant Voltage Range – C.V | V | 10 (±1) – 60 (±1) |
| Constant Current Range – C.C | A | 100 (+0, -10) – 1300 (+10. – 0) |
| Open Circuit Voltage | VDC | 95 (± 5) |
| Duty Cycle | % | 100% (44V / 1000A )
50% (44V / 1300A) |
| IP Rating | Class | 23 |
| Dimension | mm | 590*960*820 |
| Weight | kg | 185 (±5) |
