HERO TECH INVERTER MIG WELDING MACHINE IM3000

MIG SERIES (IGBT)
Features:

• Excellent MIG/MAG welding
• Constant Voltage output
• Perfect for carbon steel, stainless steel, and aluminum welding
• Electronic reactor, provide stable welding output
• Input voltage compensation (±15%)
• Small in size, lightweight, easy to operate
• Low input current draw
• Digital display for precision and easy view


  Specification	IM 3000
  Input Voltage (VAC)	380 / 415, 50 / 60Hz
  Rated Voltage (%)	±18 %
  Rated Input (KVA / KW)	10.4 / 7.8
  Power Factor (%)	68.70%
  Efficiency (%)	83.10%
  Output Current (ADC)	50 – 250
  Output Voltage (VDC)	16.5 – 26.5
  Open Circuit  Voltage (VDC)	50
  Duty Cycle – 10 minutes (%)	60
  Welding Method	MIG / MAG
  Wire Diameter (Ø)	0.6 / 0.8/1.0
  Insulation Class (Level)	F
  IP Rating (Level)	IP21S
  Wire Feed Speed (M / min)	1.5 – 15
  Motor Voltage (DCV)	24
  Dimension (W*D*H) mm	270*480*420
  Weight (KG)	30
