EZYLIF BENCH DRILLING MACHINE VD25

SPECIFICATION
Model: VD25
Max Driling Diameter: 25 mm (1″)
Motor Power: 1100 w
Spindle Travel: 120 mm
Class of Speed: 12
Speed 50Hz: 150-2450 rpm
Spindle Taper: MT3

Max Distance:
• Spindle axis to surface of column – 220 mm
• Spindle end to surface of table – 765 mm
• Spindle end to surface – 1225 mm

Swing: 440 mm
Table Size: 350 x 350 mm
Base Size: 470 x 360 mm
Column Diameter: 92 mm
Height: 1710 mm
Packing Dimension: 1415 x 650 x 305 mm
