EZYLIF BENCH DRILLING MACHINE VD20

SPECIFICATION
Model: VD20
Max Driling Diameter: 20 mm (3/4″)
Motor Power: 900 w
Spindle Travel: 85 mm
Class of Speed: 16
Speed 50Hz: 180-2770 rpm
Spindle Taper: MT2

Max Distance:
• Spindle axis to surface of column – 180 mm
• Spindle end to surface of table – 620 mm
• Spindle end to surface – 810 mm

Swing: 360 mm
Table Size: 290 x 290 mm
Base Size: 460 x 270 mm
Column Diameter: 72 mm
Height: 1200 mm
Packing Dimension: 1010 x 490 x 275 mm
