DLS714Z 190 mm (7-1/2″) 18Vx2 Cordless Slide Compound Miter Saw
WhatsApp us
Features
- Large cutting capacity; Crosscuts up to 52 x 300 mm (2-1/16″ x 11-3/4″) at 90°.
- Miters 0-47 ° left and 0-57 ° right; bevels 0-45 ° left and 0-5 ° right.
- ADT (Automatic Torque Drive Technology) adjusts speed and torque during operation for optimum performance.
- Large dimensional lumber cutting capacity: 52 x 300 mm (2″ x 12″) at 90° and 52 x 212 mm (2″ x 8″) at 45°.
- Positive miter stops at: 0°, 15°, 22.5°, 30° and 45° left and right.
- Linear ball bearing system engineered to deliver “dead-on” accurate cuts.
Specification
| Blade Diameter | 190 mm (7-1/2″) |
| Miter Angle | 47° L / 57° R |
| Bevel Angle | 45° L / 5° R |
| Max Cutting Capacity | 90°: 52 x 300 mm (2-1/16 x 11-3/4″) at 45° left: 40 x 300 mm (1-9/16 x 11-3/4″) at 5° right: 40 x 300 mm (1-9/16 x 11-3/4″) |
| No Load Speed (RPM) | 5,700 |
| Dimensions (L x W x H) | 655 x 430 x 445 mm (25-3/4″ x 17″ x 17-1/2″) |
| Net Weight | 12.6 kg (27.8 lbs.) |
| Work Amount (approx.) | 350 pcs with BL1850B x2 SPF Material 2×4″ |
| Standard Equipment TCT Saw Blade (B-03850), Dust Bag (1228520), Holder Set, Vertical Vise, Hex Wrench, Triangular Rule Available Option
|
|
